Mainboard
Available MB Thin-mini ITX (170mm*170mm)
Platform ①Intel Gemini Lake-R: J4125
②Intel Jasper Lake: N5095
③Intel Comet Lake: i3-10110U/i5-10510U/i7-10710U
④Intel Ice Lake:i3-1000NG4/i5-1030NG7/i7-1060NG7⑤Intel Tiger Lake:i3-1115G4/i5-1135G7/i7-1165G7
⑥Intel H510
⑦Intel H610
OS Windows 11 home/Windows 11 Pro/ Linux
Dimension(L*W*H) 540MM*320mm*145.48mm
Material Metal and Plastic
Memory 1* or 2* SO-DIMM DDR4 (according to MB)
8GB/16GB up to 64GB (according to MB)
Storage SSD 2260/2280, 128GB/256GB/512GB
HDD 2.5 inch 500GB/1TB/2TB
Camera Front 2.0m / Rear 8.0m
WIFI/Bluetooth WIFI: IEEE 802.11 b/g/n or ac, or WIFI 6/ BT 5.0
Side I/O board Interface USB 3.0 / USB 2.0* 2
Type-C (Option)
Power button with LED
HDD R/W LED
Power AC 100~240V, 50/60Hz, 60W/12V/5A, ₵5.5mm
AC 100~240V, 50/60Hz, 65W/19V/3.42A, ₵5.5mm
AC 100~240V, 50/60Hz, 90W/19V/4.7A, ₵5.5mm
AC 100~240V, 50/60Hz, 120W/19V/6.3A, ₵5.5mm
