Form Factor SSF
Dimension 200mm*55mm*200mm (L*W*H)
Volume 2L
Color Black
House Metall and Plastic
VESA 10*10 cm
Available MB Thin-mini ITX (170mm*170mm)
Platform ①Intel Gemini Lake-R: J4125
②Intel Jasper Lake: N5095
③Intel Comet Lake: i3-10110U/i5-10510U/i7-10710U
④Intel Ice Lake:i3-1000NG4/i5-1030NG7/i7-1060NG7⑤Intel Tiger Lake:i3-1115G4/i5-1135G7/i7-1165G7
⑥Intel H510
⑦Intel H610
WIFI/Bluetooth Type:1216 on board
WIFI: IEEE 802.11 b/g/n or ac, or WIFI 6
BT 5.0
Memory 1* or 2* SO-DIMM DDR4 (according to MB)
2*SO-DIMM 8GB, 16GB, 32GB
Storage SSD 2260/2280 Type, 128GB/256GB/512GB
HDD 2.5inch 500GB/1TB/2TB
I/O USB 3.2 GEN1(Type-A)×2
USB 2.0 GEN1(Type-A)×2
HDMI®*1, standard, HDMI® out
DP*2, standard, DP out
LAN(RJ45)*1
DC IN Jack *1,₵5.5mm
Audio Audio in/out 3.5mm*1
Power AC 100~240V, 50/60Hz, 60W/12V/5A, ₵5.5mm
AC 100~240V, 50/60Hz, 65W/19V/3.42A, ₵5.5mm
AC 100~240V, 50/60Hz, 90W/19V/4.7A, ₵5.5mm
AC 100~240V, 50/60Hz, 120W/19V/6.3A, ₵5.5mm
Sofrware Support OS Windows 11 home / Windows 11 pro / Linux
